Compressor Part

Summary:
Phoenix Specialty Manufacturing specializes in short to medium run jobs such as this, our experience with compound tooling coupled with a state of the art tool room allows us to quickly produce precision specialty tooling.
Industry: Compressor Industry
Application: N/A
Quantity: 1,000
Material: 302 Stainless Steel
Die Type: Compound, short run
Challenges: Since the customer did not have a print, a sample was provided and using our Vision Inspection equipment we created a print. We then worked with the customer to add tolerances. In the end this part had a total of 58 characteristics for inspection. For a short run job like this a compound die was most cost effective for the customer. The die challenges where producing a compound die cutting .008 material with 10 punches with the center punch being a clover leaf shape, with a .022 wall thickness at 4 points, this punch was machined using a turning center, machining center, wire EDM, and RAM EDM.
Special Operation: None
Special Services: None
Special Packaging: None
Special Requirements: 58 Inspection Characteristics
